Product Overview
CIU32L030F8P7TU is a cost-effective, ultra-low-power secure 32-bit MCU launched by Huada Electronic Design. Adopting advanced ARM Cortex-M0+ architecture with a maximum operating frequency of 48MHz. The compact TSSOP20 package features ultra-small size and high integration, reducing PCB layout space and BOM cost. With excellent ultra-low power performance and industrial-grade wide temperature stability, it is widely applicable to various battery-powered smart IoT and industrial embedded devices.
Core Key Specifications
-
Core & Frequency: 32-bit ARM Cortex-M0+ core, maximum 48MHz operating frequency, supports single-cycle multiplication for efficient operation
-
Memory Configuration: 64KB embedded Flash memory with 100,000+ full-temperature erase-write cycles, 6KB high-speed SRAM
-
Operating Conditions: Wide working voltage of 1.8V~5.5V, industrial temperature range from -40℃ to 105℃
-
Package Type: Ultra-compact TSSOP20 surface-mount package, suitable for miniaturized and highly integrated product design
-
Low Power Performance: Multiple configurable sleep and low-power working modes, ultra-low static power consumption, greatly extending battery service life
Onboard Peripherals & Security Features
-
High-Precision Analog Modules: Integrated 12-bit high-speed ADC, 2 ultra-low-power voltage comparators and on-chip temperature sensor
-
Diversified Communication Interfaces: Equipped with UART, LPUART, SPI and I2C interfaces, all supporting sleep wake-up function to meet diverse communication needs
-
Rich Functional Modules: Built-in multi-channel DMA, multi-function general-purpose timers, independent watchdog timer and RTC real-time clock
-
Industrial Anti-Interference Performance: Optimized circuit protection design, excellent EMC/ESD resistance, stable and reliable long-term operation in complex industrial environments
Product Advantages
-
Ultra-Low Power Consumption: Professional low-power chip architecture design, multiple power consumption modes, perfectly matching long standby requirements of battery-powered devices
-
Miniaturization & High Integration: QFN20 tiny package saves PCB space, complete on-chip peripherals eliminate the need for auxiliary chips and reduce overall project costs
-
Stable Supply & High Cost-Performance: Original genuine Huada chip, sufficient spot stock, stable domestic supply chain and favorable bulk price
-
Complete Technical Support: Provide official datasheets, development codes, debugging guidance and one-stop FAE technical support
Typical Applications
-
Smart Metering: Smart water meters, gas meters, electricity meters and industrial flow monitoring terminals
-
Smart Security: Intelligent door locks, access control systems, infrared sensing alarm equipment
-
IoT Sensing Devices: Low-power wireless sensor nodes, portable detection and wearable smart devices
-
Smart Home Products: Miniature smart switches, battery-powered small home appliances and control modules
-
Industrial Monitoring: Low-power industrial detection terminals, environmental monitoring and safety protection equipment
Our Services
-
100% original genuine CIU32L030F8P7TU chips with strict quality inspection
-
Support sample testing and customized bulk wholesale orders
-
Long-term stable inventory supply and efficient global shipping
-
Free official technical documents and professional one-on-one technical consulting
-
Reliable after-sales quality assurance system
